Features：

· 1. 8-channel microphone input, 8-channel (4 groups) stereo input
· 2. With 48V phantom power
· 3. 1-8 channels with 80Hz low-cut function, 13-16 channels with lotus input interface, convenient wiring
· 4. Input high, middle and low 3 band balance
· 5. 4 auxiliary outputs, 4 AUX transmissions, 2 FX transmissions,
· 6. Input each channel with main output MAIN, group group, monitor PFL switch, easy to choose
· 7. The monitor indicator and the peak indicator are shared
· 8. With MP3 playback function, MP3 with LCD screen, display songs
· 9. With Bluetooth function, you can directly Bluetooth input audio
· 10. With recording function, you can record directly with U disk
11. Can communicate directly with the computer, the computer USB cable can output audio to the mixer
12. Built-in 2 DSP digital effectors, 198 kinds of effects, good effects, comparable to professional effectors
· 13 effect modes with LCD display, intuitive display and easy operation
· 14. One main output, with balanced and unbalanced output ports, two faders independently controlled, 60mm imported faders
· 15. Real two-group output, independent control of two faders
· 16. Stereo monitor output, you can monitor with headphones or external speakers
· 17.. Stereo Auxiliary Return
·
· 18. Built-in switching power supply, convenient wiring
· 19. Standard dual 12-segment beam level meter, which accurately indicates the level
· 20 unique appearance design, SMT surface mount technology, reliable performance
21. With recording output and recording playback input

Technical Parameters
Frequency response: +0.5dB/-0.5dB (20Hz-20kHz)
Total harmonic distortion: 0.03%@+14dBu (20 Hz-20kHz)
Input channel: 16 channels:
Mono: 8;
Stereo: 4
Output channel: STEREO OUT: 2;
Grouping: 4, AUX (including FX)
USB input, with lyrics display and Bluetooth connection function
USB audio: USB audio 2.0 compatible
Sampling rate: up to 192kHz,
Bit depth: 24-bit
Phantom power supply voltage: +48V
Built-in double digital effect: 99 programming
Power consumption: 30W
