Product introduction:

1. Karaoke effect with speaker processor function, each part of the function can be adjusted independently.

2. Adopt 24Bit data bus and 32Bit DSP.

3. The music has 7-band parameter equalization. Music to main output high-pass filter: 12dB/24dB (0Hz-303Hz)

4. The microphone has 15-band parameter equalization. With microphone pressure limit function.

5. The main output is equipped with 5-band parameter equalization. There is a compression limiter.

6. The center output, subwoof output and rear output (X3 does not have this output) are equipped with 3-band parametric equalization.

7. The microphone has 4 kins modes of feedback suppression : OFF 1 2 3.

8. 16 modes can be stored.

9. Microphone output, main output, center output, subwoof output, rear output (X3 does not have this output) are equipped with pressure limit and delay function.

10. There are manager mode and user mode. User mode cannot be stored after adjusting parameters.

11. The machine has a full-featured menu, which can be set through a powerful PC interface.

Features: music

1. Music parameter equalization: 7-band

2. Music to main output high-pass filter: 12dB/24dB (0Hz-303Hz)

microphone

1. There are four microphone FBE modes: OFF 1 2 3

2. With microphone pressure limit function

3. 15-band microphone parameter equalization

Reverb effect echo:

1. Echo low-pass filter: 5.99Hz-20.6KHz

2. Echo high-pass filter: 0Hz-1000Hz

3. Echo parameter equalization: 3-band

4. Echo level: 0～99.9%

5. Direct echo sound level: 0～99.9%

6. Echo pre-delay: 0～500ms

7. Pre-delay of echo right channel: 0～±50%, (relative to left channel)

8. Echo total pre-delay: 0～500ms

9. Echo right channel delay: 0～50%, (relative to left channel echo delay time)

10. Echo repetition: 0～90%

reverberation:

1. Adjustable range of reverberation low-pass filter : 5.99Hz-20.6KHz

2. Adjustable range of reverberation high-pass filter: 0Hz-1000Hz

3. Adjustable range of reverberation level: 0～99.9%

4. Adjustable range of direct reverberation sound: 0～99.9%

5. Adjustable range of echo pre-delay: 0～200ms

6. Adjustable range of reverberation time: 0～3000ms

Main output (working mode: singing/dancing (automatic/manual), including all parameters except pressure limit, delay, mute)

1. Music level: 0～200%

2. Direct sound level: 0～200%

3. Echo level: 0～200%

4. Reverberation level: 0～200%

5. 5-band music parameter equalization

6. Compression limiter

7. Left channel delay: 0～50ms

8. Right channel delay: 0～50ms

9. Left channel mute function

10. Right channel mute function

Central output (working mode: singing/dancing (automatic/manual), including all parameters except pressure limit, delay, mute)

1. Music level: 0～200%

2. Direct sound level: 0～200%

3. Echo level: 0～200%

4. Reverberation level: 0～200%

5. High-pass filter: 0Hz-303Hz

6. 3-band parameter equalization

7. Compression limiter

8. Delay: 0～50ms

9. Mute function

subwoof output (working mode: singing/dancing and (automatic/manual), including all parameters except pressure limit, delay and mute)

1. Music level: 0～400%

2. MIC direct sound level: 0～200%

3. High-pass filter: 12dB, Q 0.4 ~ 1.5, /Bessel 24dB/Butterworth 24dB/Link Riley 24dB/USER 12dB/USER 24dB (0Hz-303Hz)

4. Low-pass filter: 12dB, Q 0.4 ~ 1.5, /Bessel 24dB/Butterworth 24dB/Link Riley 24dB/USER 12dB/USER 24dB (0Hz-303Hz)

5. 3-band parameter equalization

6. Compression limiter

7. Delay: 0～50ms

8. Mute function

Rear output (working mode: singing/dancing and (auto/manual), including all parameters except pressure limit, delay, mute) (X3 does not have this output)

1. Music level: 0～200%

2. Direct sound level: 0～200%

3. Echo level: 0～200%

4. Reverberation level: 0～200%

5. High-pass filter: 0Hz-303Hz

6. 3-band parameter equalization

7. Compression limiter

8. Left channel delay: 0～50%

9. Right channel delay: 0～50%

10. Left channel mute: mute/unmute

11. Right channel mute: mute/unmute

system

1. Two music input ports: 1/2

2. Music input gain: 0dB/3dB/6dB (user mode is not adjustable)

3. Keypad lock password and system mode password

Specifications and performance indicators:

Maximum input level: 4V (RMS).

Maximum output level: 4V (RMS).

Music channel gain:

MAX: 12dB Microphone sensitivity 64mV: (out: 4V).

Signal to noise ratio:> 80dB

Input voltage: 220V 50Hz

Dimensions (L×W×H): 483*225*52mm

Net weight: 3.7 Kg.

Gross weight: 4.5 Kg.
